High-Definition Analog & IP Input Support
8 Turbo HD/AHD/CVI/CVBS self-adaptive video inputs
8 analog video + 4 audio input channels
Supports 16 IP cameras up to 8MP resolution
Offers flexible hybrid deployment
AccuSense Deep Learning Technology
Intelligent human and vehicle detection with high accuracy
Filters out false alarms caused by animals, leaves, rain, etc.
Behavior analysis supports 4-channel detection simultaneously
Ideal for intrusion detection, line crossing, region entry/exit, etc.
Smart Video Analytics (VCA)
Supports multiple VCA events for both analog and smart IP cameras
Enables proactive security with real-time event alerts
Recording & Resolution Support
8MP: 8fps
5MP: 12fps
4MP: 15fps
3MP: 18fps
1080p: 25fps (PAL) / 30fps (NTSC) per channel
4K UHD HDMI output for sharp display monitoring
Efficient Video Compression
H.265 Pro+, H.265 Pro, H.265, H.264+, and H.264 supported
Maximizes recording duration with reduced bandwidth usage
Storage & Expandability
1 SATA interface supports HDD up to 10TB
CVBS output supported for traditional analog monitors
Alarm & Networking
8 alarm inputs and 4 alarm outputs for event-triggered automation
1 RJ45 10/100/1000 Mbps network interface
Enables remote monitoring, playback, and smart search
Compact Build
Standalone 1U case design
Ideal for businesses, factories, retail chains, and high-security environments requiring accurate motion detection
